Power to weight ratio: watts per kilogram explained and how to boost yours
Unless you only ever ride on pancake-flat surfaces, improving your power-to-weight ratio is a must
'Power-to-weight ratio' is something that more and more cyclists are looking at, even at amateur level, often when climbs are involved. It's used by all the contenders for the Grand Tours too as one of the keys to unlocking the door to greatness.
Unlike with cars, cyclists can not buy more horsepower, even e-bikes don't actually give you much and if you're a rider that averages over 30kph on a ride, you're just dragging a battery around with you for no reason.
Cyclists, along with other athletes can train muscles and build stamina over time meaning that our bodies are able to naturally produce more power. However, this is not a walk, or rather ride, in the park.
Sure, improving your aerobic fitness does indeed help you increase your power output from the muscles in your legs et al, there is a limit to what these gains can give you.
Thankfully, the power you put out is not the only thing that shows off the performance of most cyclists. It's on how much mass you have to ride around with too.
The act of riding uphill requires a certain amount of power to push against gravity, meaning the less mass you carry the less power.
Unless you live in Norfolk on perfectly flat and, on occasion, smooth roads it is not just maximum power but power factoring in bodyweight, or rather the power-to-weight ratio (P/WR)… This is usually shown in Watts per kilogram (W/KG).
To work it out you need some maths. All you need to do is divide your absolute max power output in Watts by how much you weight in KGs. So, if we use an example, if a rider who weights 80kg has a maximum power output of 280w his P/WR is 3.5w/kg.
Why does it matter?! I imagine you barking at your phone/laptop/tablet etc as you read this... Well, it is a brilliant predictor of performance. Say you had two riders, lets say A and B.
The maximum power of A is 250w, whereas B can only manage 225w. If this was on a beautifully smooth and flat indoor track A would be faster. But, on a hilly course the P/WR comes into it.
If both have the same weight then, of course, A would again be faster. But is A was 80kg and B was 68kg the P/WR for A would be 3.13w/kg with B's sitting at 3.31w/kg, this means that B would scamper away on the climbs.
Table: Power-to-weight ratio/watts per kilogram for a range of rider weights and power outputs
|Row 0 - Cell 0||120w||150w||180w||210w||240w||270w||300w||330w||360w||390w|
Understanding power-to-weight ratio/watts per kilogram
With power-to-weight ratio being calculated by the sum of power (watts) ÷ mass (kg), I hope that even the least maths minded people, of which I am included, can understand there are three ways to up your P/WR:
• Increase your power output while keeping your weight constant.
• Keep your power output constant while decreasing your weight.
• Increase your power output while also decreasing your weight.
Also if your power output increases at the same time as your weight you P/WR may not change. This is the same for cyclists who lose weight with losing power - Which is something that will come up later.
Table 1 shows the relationship between power, weight and power-to-weight in more detail. Looking at Table 1, notice how P/WR rise as power output rises and bodyweight falls — i.e. higher and further to the right in this table. Notice too how any given power-to-weight ratio (we’ve highlighted 3W/kg) can be achieved at much lower absolute power outputs when the rider’s mass is low. For example, a 50kg rider churning out just 150 watts has the same power-to-weight ratio as a 90kg rider churning out 270.
Now suppose this 90kg rider wants an improved power-to-weight ratio. If he or she sheds 10kg (down to 80kg), P/WR jumps from 3.0 to 3.4W/kg — that’s a bigger improvement than staying at the same weight and working on aerobic fitness to increase power output to 300W. This underlines why shedding excess body mass (fat) is so effective at boosting performance — even if your aerobic fitness remains the same.
How good is a good power-to-weight ratio?
What would be a ‘good’ P/WR? Well, this depends on the time period and the level at which you’re riding. Dr Andrew Coggan, an internationally acclaimed exercise physiologist, has compiled some typical power-to-weight ratios, which are shown in the Table below.
Table: Typical power-to-weight ratios for different level cyclists
|Rider type||5 mins||20 mins||1 hour|
It’s not surprising to observe that the pros have superior power-to-weight ratios regardless of time period. What’s more intriguing is that compared to amateur and recreational riders, the typical one-hour power-to-weight ratio of a pro rider is only fractionally lower than the 20-minute figure. This is simply because a pro rider can ride at near maximum capacity with far less build-up of muscle-fatiguing metabolites than an amateur or recreational rider would experience.
What affect does power-to-weight ratio have when battling wind and hills?
As we saw earlier, shifting mass uphill means that you have to work against the force of gravity. This explains why power-to-weight ratio becomes especially important when climbing. However, absolute power is still important.
To illustrate this, let’s compare power requirements of a 70kg and 80kg rider riding a 6kg road bike up a hill of seven per cent gradient at 16kph (10mph) in still winds. Using data on rolling and aerodynamic resistance, we can calculate that an 80kg rider would have to maintain an average power output or around 298W, requiring a power-to-weight ratio of 3.73W/kg. The 70kg rider would only need to average 266W to ride up the same hill at the same speed on the same bike. However, although it’s 32W less power overall, this translates into a slightly higher power-to-weight ratio of 3.80W/kg.
Two riders on a 6kg road bike, travelling at 16kph up a 7 per cent gradient
Why is this? In simple terms, although much of the riders’ power requirements are a function of body mass (because they’re climbing), there’s an extra, fixed amount of work that has to be done to push the air out of the way (i.e. overcoming aerodynamic resistance), which is the same for both riders. As speeds rise, the contribution from aerodynamic resistance becomes proportionately greater. This in turn begins to favour absolute power output over power-to-weight. Of course, it’s worth bearing in mind that, in a real-life scenario, the heavier rider is likely to be physically larger and have greater frontal surface area, increasing their aerodynamic resistance further (a discussion to be explored another time).
To illustrate this, let’s now suppose that the riders are travelling twice as fast (32kph) but the gradient is half as steep (3.5 per cent). The figures now become:
The rate of ascent overall is still the same and the 70kg rider still requires around 32W less power than the 80kg rider to maintain a speed of 32kph. However, both riders have had to find a massive 163W extra to overcome the increased aerodynamic resistance experienced at 32kph compared to the resistance at 16kph.
What does this mean in practice?
Essentially, the hillier the terrain, the more your power-to-weight ratio matters. The flatter the terrain, the less power-to-ratio matters and the more absolute power output matters (figure 1). We can draw another conclusion: when power-to-weight ratios are identical, the rider with the highest
absolute power will be faster. For example, if rider A weighs 80kg and can sustain 240W, while rider B weighs 70kg and can sustain 210W, they both have a power-to-weight ratio of 3W/kg. But A will be faster because he/she will have more power to overcome aerodynamic and frictional drag.
The flatter the terrain, the more important absolute power becomes.
The hillier the terrain, the more important power-to-weight becomes.
Testing your own power output
Calculating your own power-to-weight ratio requires only two measurements: your weight and your maximum sustainable power output. The first is easy to measure — just hop on some accurate bathroom scales. The second requires a power output measurement. To do this, you’ll need to use a bike with a reliable power meter fitted (SRM, Powertap, etc) or better still, a stationary bike with accurate power metering (e.g. WattBike) where you can pedal furiously without needing to slow down for bends, traffic, etc.
To measure maximum sustainable aerobic power, ride gently for 10 minutes to make sure you’re thoroughly warmed up. Take a couple of minutes’ rest, then ride as hard as you possibly can for 20 minutes and record your average power output figure in watts. This is your 20-minute maximum sustainable power output. Your one-hour maximum sustainable power output will be five to 10 per cent lower (depending on fitness) than this figure, e.g. a 20-minute figure of 275W would equate to around 260W for an hour. Your five-minute maximum power will be around 10 per cent higher than the 20-minute figure, e.g. in this example, around 295W).
Practical tips for improving your power-to-weight ratio
We’ve seen that increasing power, reducing bodyweight or a combination of both can significantly improve your power-to-weight ratio. But how can you best achieve this? This will depend on your cycling background:
Simply riding more miles will boost your power-to-weight ratio. Putting in more miles will not only boost your level of aerobic fitness (i.e. your sustainable power output); you’ll almost certainly lose a bit of excess body fat in the process. For example, if you drop from 86 to 82kg and increase your 20-minute power output from 210 to 235W, your power-to-weight ratio increases from 2.4W/kg to a very respectable 2.9W/kg.
Fitter and more experienced riders
You need to be a bit more focused than simply adding more miles. Yes, more miles might result in reduced bodyweight, but add too much extra volume and you run the risk of fatigue and burnout. Moreover, an attempt to reduce weight when your body-fat levels are already quite low can lead to muscle mass loss as well as fat loss. Given power is generated within muscle tissue, you might end up reducing your weight but losing some power with it, resulting in minimal improvements in power-to-weight ratio. In fact, remembering that absolute power is still very important, you might be worse off overall.
A better option is to include some specific training to boost maximal power output. This includes sessions such as intervals (long and shorter, more intense), hill repeats and some threshold rides. Because these sessions are quite demanding, make sure you build in sufficient recovery time into your weekly schedule — it’s during recovery that your muscles adapt and become more powerful.
Another useful strategy, especially for more accomplished riders, is to perform some regular weight training. Studies have shown that performing heavy resistance training for the key cycling muscles (quadriceps, hamstrings, buttocks and calves) not only boosts muscle efficiency, it can help prevent the loss of muscle power during periods of high-volume training, or during periods of weight loss.
Regardless of your riding ability, consuming a healthy diet with a minimum of sugary, fatty and processed foods will play a part in improving power-to-weight ratio. All other things being equal, higher intakes of sugar and sugary foods in particular have been unequivocally linked with higher levels of body fat (ref 1,2). Unlike muscle tissue, excess body fat blunts power-to-weight ratio and contributes nothing to power output. By the same token, a plentiful intake of dietary protein is recommended, especially after training. Protein is needed for recovery and repair after training, and studies show that higher intakes of protein can help prevent muscle mass loss when training volumes are high.
1. BMJ. 2012 Jan 15;346:e7492. doi: 10.1136/bmj.e7492.
2. Obes Rev. 2013 Aug;14(8):606-19.
